Sound absorbing panels
acoustic wall panels

Play by Ear is the sole-distributor for ES Panels –

Starting from SG78.50

Features:
Applicable for sound absorbing / used for sound blocking & insulation (sound proofing)
Excellent acoustic performance
High density acoustic material -Rockwool 100kg/m3
Super thick 50mm for better sound absorption
Premium plywood (does not warp over time
unlike cheaper MDF wood)
Impeccable craftsmanship
Scratch-resistant upholstery
Portable and easy installation
Customizable sizes and color
Easy maintenance

READY TO BUY – IN STOCK

On-site installation available – please email

High density Acoustic material specifications:- 80kg/m3 density
– Sound absorption coefficient (EN ISO 354 / ASTM C423-01) 50mm (NRC) : 0.9-1.0
– European fire classification : A 1 (according to EN13501-1)
– Thermal conductivity (according to ASTM C518) : 20oC λ Value (W/mK) between 0.034 – 0.036
– Water absorption EN 1609
– Partial immersion 0.5kg/m2 – 1.0kg/m2
– Melting Point ASTM E794 ASTM E794 > 1000°C

Excellent acoustic properties

Designed to combat/tackle noise pollution, our thick EF acoustic panels will solve all your acoustic treatment needs. It serves three primary functions, a) to reduce sound levels b) absorb excess sound reflections (hence hearing only the primary instance of the actual sound). c) acoustic correction

Because sound waves travel in all directions, they will hit whatever they encounter – be it walls, furniture, floor, people, etc. Our EF acoustic panels help to absorb the excessive sound waves, resulting in the reduction of both the intensity and the unwanted echos, ultimately leading to the hearing of only the primary instance of the intended sound.

50mm thickness / 100kg/m3 - High density mineral rockwool

When it comes to sound absorption, you require high density. or With sound absorption, you require high density. Energy loss increases as the surface friction increases, hence the sound absorption coefficient increases correspondingly.

For our range of acoustic panels, we do not compromise on quality.
We use one of the thickest and highest density rockwool insulation (mineral wool) available – 50mm thickness, weighing at 100kg/m3. When compared to fiberglass insulation (a much cheaper alternative), rockwool has a 37% higher R-value which makes it three times denser. Most acoustic panels in the market uses thinner and less denser rockwool or mineral wool.

Winning combo - aesthetics and acoustics

Whether it is for professional audio recording studios, audiophile music rooms, places of worship, offices, gyms or even bedrooms, you don’t need to be a maestro to enjoy good sound acoustics.

Our EF acoustic panels are meticulously wrapped individually using  industrial practice -‘tension & release’ method, which means you can say goodbye to wrinkles or creases.

The fabric we use is permeable to air (a must for sound absorbing panels) and scratch resistant as well, making it indestructible, robust and long-lasting for years to come.

Safety comes first

The rockwool insulation material inside our wrapped fabric is made of a natural-based volcanic stone which has the ability to withstand temperatures of over 1000°C without melting (according to DIN 4102-17 and ASTM E794).

Our non-combustible insulation material achieves the highest European fire classification – A 1 (according to EN13501-1) It’s thermal conductivity (according to ASTM C518) has a 20oC λ Value (W/mK) between 0.034 – 0.036. It is also water repellent and moisture resistant (tested under EN 1609)

EF ACOUSTIC PANEL OFFICIAL

Factory available sizes

SIZE A : 305mm x 1218mm x 50mm (factory color)
Price excludes delivery fees SG$20 flat charge within Singapore. Self-collection FREE at Bugis main store.

SG$78.50

SIZE B : 610mm X 1218mm x 50mm (factory color)
Price excludes delivery fees SG$25 flat charge within Singapore. Self-collection FREE at Bugis main store.

SG$96.35

SIZE C : 1218mm X 1218mm x 50mm (factory color)
Only self-collection FREE at Bugis main store.

SG$172.85

SIZE D : Custom size & colors – Ready within 2 working days

E04 ESPRESSO (Factory color)

Purchase now
Ready stock in Singapore

Play by Ear is the sole-distributor for ES Panels –

Starting from SG78.50

READY TO BUY – IN STOCK

CASH & CARRY

On-site installation available

Customize sizes and colors available (ready within 2 working days)

EF ACOUSTIC PANEL OFFICIAL

Please whatsapp us at 91798110 to enquire, purchase or check on stock level.

Viewing or pickup at our main branch – 245B (level 3) Victoria Street, Bugis Village, Singapore 188032

Customize colors

E01 STEEL

E02 HAZE

E03 HEATHER

E04 ESPRESSO

E05 BLACK

E06 MOON

E07 TEAL BLUE

E08 IRIS

E09 OCEAN

E10 ROYAL

E11 AQUA

E12 LAGOON

E13 ROSE

E14 FLAME

E15 CHERRY

E16 ILLUE

E17 MANGO

E18 ORANGE

E19 NEON RED

E20 RUST

E21 WINTER

E22 CHAMP

E23 BUTTER

E24 ASH

E25 BAMBOO

E26 NUT

×
