Yamaha
MODX8

Sophisticated Dynamic Control

Music is expression. MONTAGE adds a new level of expression with the Motion Control Synthesis Engine. This engine allows a variety of methods to interact with and channel your creativity into finding your own unique sound.

Yamaha MONTAGE 6 Synthesizer Keyboard Key points

  • Motion Control Synthesis Engine, find tune your creativity into finding your own unique sound
  • 128 note polyphony for dropout free performances even with multi-layered effects

Free Gifts

  • Limited edition PBE leather journal cover

Comes With

  • Power adapter
  • Free Delivery
  • 1 year local Yamaha (Singapore) warranty

Purchase online at

SKU MONTAGE-6-1 Categories , , Tags , , , ,

Additional information

Number of keys

61

Action

FSX Action

Key material

Matte plastic

Sound technology

Yamaha Advanced Wave Memory 2 (AWM2) Stereo Sampling, Yamaha FM-X

Polyphony

128

Tones

Preset: 5.67 GB (when converted to 16 bit linear format), User: 1.75 GB

Amplifier output

Not applicable

Speaker size

Not applicable

Colour

Black

Piano stand

None

Dimensions and Weight

1,037 x 396 x 131 mm, 15.0 kg

Description



Full Specifications

Size/Weight
Dimensions
Width
1,333mm (52-1/2″)
Height
160mm (6-1/16″)
Depth
404mm (15-7/8″)
Weight Weight
13.8 kg (30 lbs 7 oz)
Control Interface
Keyboard
Number of Keys 88
Type GHS Keyboard
Initial Touch Yes
Aftertouch No
Tone generator
Tone Generator
Motion Control Synthesis Engine AMW2: 8 Elements FM-X: 8 Operators, 88 Algorithms
Maximum Polyphony
AWM2: 128 (max.; stereo/mono waveforms) FM-X: 64 (max.)
Multi Timbral Capacity
16 Parts (internal), Audio Input Parts (A/D*, USB*) *stereo Part
Wave
Preset: 5.67 GB (when converted to 16 bit linear format), User: 1.00 GB
Performance Approx. 2,000
Filter 18 types
Effects
Reverb x 12 types, Variation x 76 types, Insertion (A, B) x 76 types*, Master Effect x 15 types *A/D part insertion x 71 types (Preset settings for parameters of each effect type are provided as templates) Master EQ (5 bands), 1st part EQ (3 bands), 2nd part EQ (2 bands)
Other
Controllers
Master Volume, AD Input Gain knob, USB Volume, Pitch Bend wheel, Modulation wheel, Control Sliders x 4, Knobs x 4, Super Knob, Data dial
Display
7″ TFT Color Wide VGA LCD touch screen
Connectors
[USB TO DEVICE], [USB TO HOST], MIDI [IN]/[OUT], FOOT CONTROLLER [1]/[2], FOOT SWITCH [ASSIGNABLE]/[SUSTAIN], OUTPUT [L/MONO]/[R] (6.3 mm, standard phone jacks), [PHONES] (6.3 mm, standard stereo phone jack), A/D INPUT [L/MONO]/[R] (6.3 mm, standard phone jacks)
Power Consumption
16 W (when using PA-150B AC adaptor)
Accessories
AC adaptor (PA-150B or an equivalent recommended by Yamaha*), Owner’s Manual (this book), Cubase AI Download Information *May not be included depending on your area. Check with your Yamaha dealer.
Live Sets
Preset: 256 and more, User: 2,048
Performance Recorder
Tracks
16 Sequence tracks, Tempo track, Scene track
Recording type
Real time replace, Real time overdub, Real time punch in/out
Note Capacity
Approx. 130,000 notes
Note Resolution
480 ppq (parts per quarter note)
Tempo (BPM) 5 – 300
Songs 128 songs
Arpeggio
Parts: 8 Parts simultaneous (max.), Preset: 10,239 types User: 256 types
Sequence formats
MODX original format, SMF formats 0, 1
