Yamaha Clavinova
CLP-685 (Discontinued)

Yamaha Music Logotype

Leverage your artistic expression

Showcase your artistic expression with the Yamaha Clavinova CLP-685. Get the sound of Yamaha CFX and Bosendorfer grand pianos in your room with the Yamaha’s Pure CF engine sampling technology. Powerful amplifiers and spruce speakers produces a natural timbre that is hard to distinguish from the a fine acoustic instrument. The Yamaha Clavinova CLP-685 features the Grandtouch action that has a longer pivot point to allow the pianist to have a much better control over the tone and dynamics.

Yamaha Clavinova CLP-685 Digital Piano Key points

  • CFX and Bösendorfer Imperial piano samples
  • CFX Binaural sampling
  • 256-note polyphony
  • 49 + 480 XG Voices + GM2/GS (Song file playback)
  • GrandTouch keyboard with synthetic ebony and ivory keytops (wood is used for the white keys) with Escapements and Counterweights
  • GP Response Damper Pedal
  • Dual headphone jacks
  • (50 W + 50 W + 50 W) x 2 amplifiers
  • (16 cm + 8 cm + 2.5 cm (dome)) x 2 speaker system
  • Spruce Cone speaker
  • Speaker Box

Notes

Out of stock

Purchase online at

Additional information

Number of keys

88

Action

Grandtouch, with Escapement

Key material

Natural wooden keys (white only)

Sound technology

Yamaha CFX/Bösendorfer Sound Engine

Polyphony

256

Tones

49 Voices + 14 Drum/SFX Kits + 480 XG Voices

Amplifier output

(50 W + 50 W + 50 W) x 2

Speaker size

(16 cm + 8 cm + 2.5 cm (dome)) x 2, Spruce Cone Speaker

Colour

White polish, Black, Black polish

Piano stand

Built-in

Dimensions and Weight

1,461 x 1,027 x 477 mm, 83.0 kg

Description

As the flagship model in the series, the Yamaha Clavinova CLP-685 boasts a GrandTouch Keyboard action that features the individual key counter weights found in a grand piano for unrivaled realism in the resistance and return of each key. CFX and Bösendorfer samples absolutely sing through the powerful 300W sound system with Spruce Cone speakers. Spruce wood is used in the sound boards of Yamaha acoustic pianos because of its superior tone quality, and that same wood is used in the CLP-685 speaker cones. You will lose yourself in the sound of the binaurally-sampled CFX which is a totally immersive headphone experience. Selecting Voices and adjusting settings is easy using the intuitive user LCD interface.

If you are looking for a similar touch and feel at a lower price point, we have the Yamaha Clavinova CLP-625 and CLP-635 available as well.



Full Specifications

Size/Weight
Dimensions
Width
1,461 mm (57-1/2″) (Polished finish: 1,467 mm (57-3/4″))
Height
1,027 mm (40-7/16″) (Polished finish: 1,029 mm (40-1/2″))
Depth
477 mm (18-3/4″) (Polished finish: 477 mm (18-3/4″))
Weight Weight
83.0 kg (183 lb, 0 oz) (Polished finish: 89.0 kg (196 lb, 3 oz)]
Control Interface
Keyboard
Number of Keys 88
Type
GrandTouch Keyboard: wooden keys (white only), synthetic ebony and ivory key tops, escapement
Touch Sensitivity
Hard2/Hard1/Medium/Soft1/Soft2/Fixed
88-key Linear Graded Hammers Yes
Counterweight Yes
Pedal
Number of Pedals 3
Half Pedal Yes
Functions
Sustain (Switch), Sustain Contin uously, Sostenuto, Soft, Expression, Pitch Bend Up, Pitch Bend Down, Rotary Speed, Vibe Rotor, Song Play/Pause
GP Response Damper Pedal Yes
Display
Type Full Dots LCD
Size 128 x 64 dots
Language
English, Japanese
Panel Language English
Cabinet
Key Cover Key Cover Style Folding
Music Rest Yes
Music Braces Yes
Voices
Tone Generation
Piano Sound
Yamaha CFX, Bösendorfer Imperial, CFX Binaural Sampling
Binaural Sampling
Yes (CFX Grand Voice only)
Key-off Samples Yes
Smooth Release Yes
VRM Yes
String Resonance
Damper Resonance
Polyphony Number of Polyphony (Max.) 256
Preset Number of Voices
49 Voices + 14 Drum/SFX Kits + 480 XG Voices
Compatibility
XG (GM), GS (for Song playback), GM2 (for Song playback)
Effects
Types
Reverb 6
Chorus 3
Brilliance 7
Master Effect 11
Intelligent Acoustic Control (IAC) Yes
Stereophonic Optimizer Yes
Functions
Dual/Layers Yes
Split Yes
Duo Yes
Songs
Preset Number of Preset Songs
21 Voice Demo Songs + 50 Classics + 303 Lesson Songs
Recording
Number of Songs 250
Number of Tracks 16
Data Capacity
Approx. 500KB/Song
Compatible Data Format
Playback
SMF (Format 0, Format 1)
Recording SMF (Format 0)
Functions
Piano Room Yes
USB Audio Recorder
Playback
.wav (44.1 kHz sample rate, 16-bit resolution, stereo)
Recording
.wav (44.1 kHz sample rate, 16-bit resolution, stereo)
Overall Controls
Metronome Yes
Tempo Range 5 ‒ 500
Transpose -12 ‒ 0 ‒ +12
Tuning
414.8 ‒ 440.0 – 466.8 Hz (approx. 0.2 Hz increments)
Scale Type 7 types
Other Control
Tuning, Scale Type, etc.
Rhythm 20
Bluetooth
Yes (varies by country)
Storage and Connectivity
Storage
Internal Memory
Total maximum size approx. 1.5 MB
External Drives
USB flash drive
Connectivity
Headphones
Standard stereo phone jack (x 2)
MIDI
[IN] [OUT] [THRU]
AUX IN Stereo Mini
AUX OUT [L/L+R] [R]
AUX Pedal Yes
USB TO DEVICE Yes
USB TO HOST Yes
DC IN
Amplifiers and Speakers
Amplifiers
(50 W + 50 W + 50 W) x 2
Speakers
(16 cm + 8 cm + 2.5 cm (dome)) x 2, Spruce Cone Speaker
Acoustic Optimizer Yes
Power Supply
Power Consumption
Power consumption is described on or near the name plate, which is at the bottom of the unit.
Auto Power Off Yes
Power Supply Adaptors
Accessories
Accessories
Owner’s Manual, Data List, Warranty*, “50 Classical Music Masterpieces” Music Book, Online Member Product Registration, Bench*, Power cord *May not be included depending on your area. Check with your Yamaha dealer.
×
